Silverstone SST-TX500-G TFX power supply, 80 PLUS Gold - 500 watts

The black power supply in TFX form factor is characterized by its compact design and is therefore suitable for use in mini housings. The SST-TX500-G offers a lot of power for a power supply unit of this size and has enough capacity to easily supply hardware components from the mid-range segment with power. In addition, the power supply was designed for 24/7 use, which makes it suitable for a home server or workstation.

The features of the SilverStone SST-TX500-G TFX power supply at a glance:
– Support standard TFX form factor
– 500W continuous power output at 50 degreesC operating temperature rated for 24/7 operation
– High efficiency with 80 PLUS Gold certification to reduce wasted heat and save on electricity
– Silent running 80mm fan with 18 dBA minimum has excellent airflow and low noise, perfect for quiet home or office use
– Multiple protection circuitry
– Single PCI-E 6+2pin connectors support
– Powerful single +12V rail design, perfect for future high-end component upgrades or overclocking

The TFX power supply SilverStone SST-TX500-G TFX is suitable with its 500 watt total output power for PC components from the middle class segment. The power supply is extremely efficient, which also results from the use of high-quality electrical components. The power supply unit, certified with 80 PLUS Gold, achieves an efficiency of up to 92% with a load of 50%.

The power supply unit impresses with its particularly compact TFX form factor. This makes the SST-TX500-G TFX suitable for space-saving mini housings. SilverStone designed the power supply so that it can be used for 24/7 use without any problems. At only 18 dB (A), the fan works as quietly as a whisper, which fans of silent systems in particular will appreciate.

These features make the power supply interesting for many areas of application: Whether for office use, for multimedia applications, gaming, for a workstation or even a home server. The sleeved cables also ensure a particularly tidy look inside the housing.

High level of connectivity
The SST-TX500-G TFX also impresses with extensive connectivity despite its compact form factor. In addition to a 24-pin connector and a 4 + 4-pin connector for the mainboard, there are also two 6 + 2-pin PCIe connectors for graphics cards as well as four SATA and four 4-pin Molex connectors and a floppy disk. Connection for drives and other components ready.

Technical details:
Dimensions: 85 x 65 x 175 mm (W x H x D)
Weight: 1.38 kg
Colour: Black (lead-free paint)
Fan: Single 80mm silent HYB fan
Noise level: 18 dB (A) minimum
Efficiency: 87% ~ 90% (at 20% ~ 100% loading), 80 PLUS Gold certificate
Form factor: TFX
Power: 500 W
+ 3.3V: 18 A
+ 5V: 18 A
+ 3.3V and + 5V: 100 W.
+ 12V: 41.6 A / 499.2 W.
– 12V: 0.3A
+ 5Vsb: 2.5 A
MTBF: at least 100,000 h
Connections:
1 x 24 / 20-Pin motherboard connector (350mm)
1 x 8 / 4-Pin EPS / ATX 12V connector (450mm)
2 x 8 / 6-Pin PCIE connector (350mm / 150mm)
4 x SATA connector (350mm / 150mm x 2)
2 x 4-Pin Peripheral connector (350mm / 150mm)
2 x 4-Pin Peripheral and 1 x 4-Pin Floppy adapter connector (350mm / 150mm / 150mm)
Protection circuits:
– OVP (protection against overvoltage and under voltage)
– UVP (under voltage protection)
– SCP (short circuit protection)
– OPP (overload protection)
– OTP (overtemperature protection)
Scope of delivery:
1x TX500 Gold power supply
1x 20 + 4-pin cable (350 mm)
1x 8 (4 + 4) -pin cable (450 mm)
1x PCIe 6 + 2-pin cable (350 + 150 mm)
2x SATA cables (550 + 130 mm)
1x Molex cable (350 + 150 mm)
1x Molex floppy cable (350 + 150 + 150 mm)

Manufacturers guarantee: 3 years
