ASUS Prime B550M-A Wi-Fi II, AMD B550 motherboard - Socket AM4

Note: The following specifications regarding PCIe lanes, M.2 slot connections, and PCIe slot connections refer to the combination of a B550 chipset with a third- or fourth-generation Ryzen CPU (Zen 2 Matisse / Zen 3 Vermeer)! A BIOS update may be required for use with a Ryzen 5000 processor. This can be performed upon request by our King Mod Service.

Add BIOS update service to your cart now
Please note that this may delay shipping preparation by 1 to 4 business days!

– Offers 3x PCIe x16 slots, including 1x PCIe 4.0
– 2x M.2 slots, including 1x PCIe 4.0
– DDR4 memory up to 4866 MHz via overclocking
– USB on the I/O panel: 2x USB 3.1 and 4x USB 3.0
– A total of 4x connectors for fans and pumps
– Offers 1x 4-pin RGB header and 1x 3-pin ARGB header

The ASUS Prime B550M-A Wi-Fi II Micro-ATX motherboard in detail:
The ASUS Prime B550M-A Wi-Fi II is a Micro-ATX motherboard with the AMD B550 chipset and Socket AM4. The motherboard is suitable for AMD Ryzen 5000 and 3000 series desktop processors, as well as the 4000 G series, and supports PCIe 4.0. It supports DDR4 memory up to 4866 MHz. The motherboard is particularly suitable as a motherboard for gaming PCs and fills the trays of most common cases.

Technical Details:
– Format
– Micro-ATX (244 x 244 mm)
– Chipset
– AMD B550
– Socket:
– AM4 (for Matisse / Vermeer)
– RAM:
– 4x DDR4 (max. 3200 MHz, 4866 MHz with overclock)
– Dual-Channel
– max. 128 GB
– Slots:
– 1x PCIe 4.0 x16 (x16)
– 1x PCIe 3.0 x16 (electrical x16)
– 2x PCIe 3.0 x1
– Internal Connectors:
– 4x SATA 6G (RAID 0, 1, 10)
– 1x M.2 (M-Key, PCIe 4.0 x4 & SATA, 2242 to 22110)
– 1x M.2 (M-Key, PCIe 3.0 x4 & SATA, 2242 to 22110) 2280)
– 2x USB 3.0 (USB 3.2 Gen1, one header)
– 4x USB 2.0 (two headers)
– 1x front panel audio connector
– 1x system panel connector
– 1x SPI TPM header
– 1x S/PDIF out header
– 1x Clear CMOS jumper
– 1x speaker header
– 1x COM port header
– Fan header:
– 1x CPU cooler (4-pin)
– 1x Optional CPU cooler (4-pin)
– 2x system fans (4-pin)
– RGB header:
– 1x 4-pin RGB header (12VGRB)
– 1x 3-pin RGB header (5VDG)
– External connections:
– 1x PS/2
– 2x USB 3.1 Type A (USB 3.2 Gen 2, max. 10 Gbps)
– 4x USB 3.0 Type-A (USB 3.2 Gen 1, max. 5 Gbps)
– 1x DVI-D
– 1x HDMI 2.1
– 1x VGA
– 1x RJ-45 (Realtek, max. 1 Gbps)
– 2x Antennas (Wi-Fi 6, 802.11 ax, Bluetooth 5.2)
– 3x 3.5 mm jacks (Realtek)
 -Power supply:
– 1x 24-pin ATX12V
– 1x 8-pin ATX12V
– Package contents:
– 1x ASUS Prime B550M-A Wi-Fi II motherboard
– 1x I/O shield
– 2x SATA data cables
– M.2 mounting screws
– 1x Support DVD
– 1x User manual
