Gigabyte B860 DS3H WiFi6E motherboard, socket LGA 1851, Intel B860, ATX, DDR5

– Slots: 1x PCIe 5.0 x16 (x16) and 4x PCIe 4.0 x16 (x1)
– RAM: 4x DIMM slots for up to 256 GB DDR5 RAM up to 9066 MT/s
– Storage: 2x M.2 (1x PCIe 5.0 & 1x PCIe 4.0) and 4x SATA
– USB: 1x USB-C 3.2, 1x USB 3.1, 4x USB 2.0
– Cooling: 6x 4-pin PWM connectors for fans and radiators
– Connectivity: Wi-Fi 6E and Bluetooth 5.3

GIGABYTE B860 DS3H WiFi6E: ATX motherboard with Intel LGA 1851 socket and B860 chipset
The GIGABYTE B860 DS3H WiFi6E is an ATX motherboard with The mid-range Intel B860 chipset and the Intel LGA 1851 socket support Intels Arrow Lake processors. Its suitable for gamers who dont need to overclock their CPU.

The GIGABYTE B860 DS3H also offers WiFi6E PCIe 5.0 for graphics cards and M.2 SSDs. The DDR5 memory is overclockable, allowing you to get the most out of your RAM.

Technical Details
– Color
– Primary Color
– Silver
– Secondary Color
– Black
– Dimensions
– Length / Depth
– 244 mm
– Width
– 305 mm
– Form Factor
– Motherboard Form Factor
– ATX
– CPU
– CPU Manufacturer
– Intel
– CPU Socket
– 1851
– Motherboard
– Motherboard Chipset
– Intel B860
– RAM
– Max. RAM
– 256 GB
– Memory Type
– DDR5
– Memory Format
– DIMM
– Max. Memory Speed (Standard)
– 6400 MT/s
– Max. Memory Speed (OC)
– 9033 MT/s
– ECC Support
– Yes
– Memory Slots
– 4x
– Wi-Fi & LAN
– LAN
– Yes
– LAN Ports
– 1x 2.5 Gbit/s
– Wi-Fi / Bluetooth
– Yes
– Wi-Fi Standard
– Wi-Fi 6E
– Bluetooth Standard
– 5.3
– Wi-Fi Chip
– Intel AX211
– Cooling
– Backplate
– Yes
– M.2 Cooler
– Yes
– VRM Heatsink
– Yes
– Water Cooling
– Water Cooling
– Yes
– Internal Connectors
– CPU Power Supply
– 1x 8-pin
