Key Features
- Colour LCD display for fan speed and temperature
- Controls 4 sets of fans: CPU, VGA, SYS-1, SYS-2
- 3 Adjustable speeds: Low/Medium/High
- 5 panel buttons: SET, MODE, UP , DOWN, UP&DOWN
- Dual LCD colors + LCD off functions
- Supports up to 12V, 8W per channel
Key Features
- Colour LCD display for fan speed and temperature
- Controls 4 sets of fans: CPU, VGA, SYS-1, SYS-2
- 3 Adjustable speeds: Low/Medium/High
- 5 panel buttons: SET, MODE, UP , DOWN, UP&DOWN
- Dual LCD colors + LCD off functions
- Supports up to 12V, 8W per channel
Key Features
- Colour LCD display for fan speed and temperature
- Controls 4 sets of fans: CPU, VGA, SYS-1, SYS-2
- 3 Adjustable speeds: Low/Medium/High
- 5 panel buttons: SET, MODE, UP , DOWN, UP&DOWN
- Dual LCD colors + LCD off functions
- Supports up to 12V, 8W per channel
No products found
Specifications
Dimensions :
149mm x 42.5mm x 57mm
Fan Connectors :
4 x 3-pin fan connector / 1 x 4-pin power cable
Max. wattage per fan channel :
8W
Power Voltage :
+5V DC (Range 4.6V – 5.4V)
+12V DC (Range 11.5V – 12.5V)
Working Temperature :
0 degreesC – 50 degreesC
Store Temperature :
-10 degreesC – 60 degreesC
Net Weight :
171g
Gross Weight :
226g
LCD viewable area :
106mm (W) x 29mm (H)
Material :
Aluminum front bezel + copper column + aluminum bracket
Contents:
Ambience LCD Fan Controller x 1
Fan Connector x 1
High Temperature Sticker x 6
Screws (CM3 x 4mm) x 4
Manual x 1
Sticker x 2
