Maximum heatsink height of 28mm only to fit most of the slim low profile case without any conflict to the chassis.
Compact Heatsink Design for Mini ITX, Micro ATX, ATX, HTPC, Panel PC, Car PC and 1U server
Maximum heatsink height of 28mm only to fit most of the slim low profile case without any conflict to the chassis.
Compact Heatsink Design for Mini ITX, Micro ATX, ATX, HTPC, Panel PC, Car PC and 1U server
Maximum heatsink height of 28mm only to fit most of the slim low profile case without any conflict to the chassis.
No products found
Enables more efficient and quicker heat transfer from the core to the aluminium fins.
Integrated 75mm frameless, ball bearing fan with PWM control to minimise noise levels while providing sufficient air flow for CPU cooling during loading. This prolongs component life under a high temperature environment.
| CPU socket compatibility | Socket LGA775 |
| Intel CPU compatibility | Conroe-L with TDP of 35W, E series Celeron with TDP up to 65W with good case ventilation, Dual – Core with TDP up to 65W with good case ventilation, Core 2 Duo with TDP up to 65W with good case ventilation |
| Support motherboard types | Mini ITX, Micro ATX, ATX * |
| Air Flow (CFM) | 21.0 max |
| Bearing | Ball Bearing |
| Cable Length (mm) | 250 |
| Current (A) | 0.20 |
| DC Voltage (V) | 12 |
| Fan Dimensions (mm) | 75 (dia) x 15 (h) |
| Fan Speed (RPM) | 1100 – 2300 |
| Heat Sink Dimensions (mm) | 95 (l) x 93.5 (w) x 28 (h) |
| Life Time MTTF at 40C (h) | 50,000 |
| Noise Level (dBA) | 15 – 24.5 |
| Static Pressure (mmAq) | 1.4 |
| Weight (g) | 286 |
| Warranty | 60 months |
