Western digital Red Pro, SATA 6G, 7,200 rpm, 3.5 inches - 10 TB

The hard drives from the Red series are specially designed for continuous operation, which has become a very important target group. This makes them ideal for use in NAS systems and RAID setups. With 256 MB cache, this WD Red Pro disk offers more than enough reserves for this purpose.

The features of the Western Digital Red Pro with 10 TB at a glance:
– Professional hard drive from Western Digital
– Designed for continuous operation
– For NAS, server, workstation and raid systems
– Helium filled for large capacity, low heat and volume development
– 10 TB / 256 MB cache / 240 MB / s max. Data transfer rate

The features of the Western Digital Red Pro with 10 TB in detail
The Western Digital Red Pro with 10 TB is filled with helium and hermetically sealed. This minimizes volume, power consumption and temperatures, which enables Western Digital to accommodate more platter in a traditional 3.5-inch form factor. The disk only consumes 5.7 watts in operation and runs approximately four to five degrees below the temperature of standard hard disks. With 2.8 W in idle and 0.5 in standby mode, the remaining power consumption values of the Western Digital Red Pro 10 TB are also very low, which not only benefits the NAS system, but also the wallet.

With a data transfer rate of up to 240 MB / s, the limit of the SATA interface is far from exhausted, but the SATA 6G installed here not only offers the advantage of a higher bandwidth. The protocol was also significantly refined, for example to increase energy efficiency and optimize the transmission of several simultaneous data streams with high bandwidth.

3D Active Balance Plus in the WD Red is an advanced technology for mass balancing on two levels. Overall, it improves drive performance and reliability. Hard drives without proper mass balance can cause excessive vibration and noise in a multi-drive system, reduce the life of the hard drives, and slow performance over time. Thats why Western Digital advertises the Red Pro 10 TB hard drive with an enormous average life (MTBF) of one million hours.

Attention: Please note that this hard disk model with 26.1 mm turns out slightly higher than is the case with most other 3.5 inch HDDs. If necessary, measure whether the hard drive can fit into your PC, your NAS or into your external hard drive housing.

Technical details:
– Dimensions: 101.6 x 26.1 x 147 mm (W x H x D)
– Format: 3.5 inches
– Weight: approx. 650 g
– Capacity: 10 TB (10,000 GB)
– Speed: 7,200 rpm.
– Cache: 256 MB
– Data transfer rate: up to 240 MB / s
– Connection: SATA 6G
– Lifespan: 1,000,000 h (MTBF)
– Workload: 300 TB / year
– Noise development:
– Idle: 20 dB (A)
– Search mode: 29 dB (A)
– Power consumption (standby / idle / read / write): 0.5 / 2.8 / 5.7 W.
– Shock resistance (in operation): 30G for 2 ms
– Operating temperature: 5 – 60 degrees C
– Type: helium filled
– Product execution: OEM
– Warranty: 5 years
