The elegant midi tower for mainboards up to the ATX form factor from Jonsbo impresses with its elegant design.
No products found
The U4 Plus has a subtle exterior with brushed aluminum and a side panel made of tempered glass. The midi tower offers plenty of space for high-performance hardware and puts it in the limelight.
The features of the Jonsbo U4 Plus Midi-Tower case at a glance:
– Noble midi tower with brushed aluminum from Jonsbo
-Chic side panel made of tempered glass
– Space for mini-ITX, mATX and ATX boards
– With space for long ATX power supplies up to 220 mm
– Seven slots for graphics and expansion cards
– Up to two 2.5-inch and one 3.5-inch data carriers
The features of the Jonsbo U4 Plus Midi-Tower case in detail
Externally, the U4 Plus from Jonsbo impresses with its subtle and clear design, the chic side panel made of tempered glass and the flawless workmanship. The midi tower has a power switch and two USB 3.0 ports on the left.
With its dimensions of 205 by 391 by 395 millimeters, the U4 Plus from Jonsbo is still quite compact, but full-blown gaming hardware can be accommodated inside. In addition to a Mini-ITX, Micro-ATX or ATX mainboard, there is also space for graphics cards up to 330 millimeters in length. With seven slots there is enough space for graphics card networks and other expansion cards such as capture cards or sound cards.
The U4 Plus can hold up to two 2.5-inch and one 3.5-inch data carriers. Two 120 mm fans in the bottom and a 120 mm fan can be installed in the rear wall for cooling. There is space for two additional 120 fans in the lid of the elegant housing and reinforce the natural chimney effect, which benefits the cooling of all components. The power supply is housed in the front of the housing and can be up to 220 mm long.
– Technical details:
– Dimensions: 205 x 391 x 395 mm (W x H x D)
– Material: aluminum, steel, tempered glass
– Weight: 5.5 kg
– – Color: Black
– Form factor mainboard: Mini-ITX, Micro-ATX, ATX (up to 305 x 245 mm)
-2x 120 mm (front)
– 1x 120 mm (rear wall)
– 2x 120 mm (bottom)
– Fan (pre-installed): none
– Drive bays:
– 1x 3.5 inch
– 2x 2.5 inches
– Power supply: ATX (optional)
– Expansion slots: 7
– I / O panel:
– 2x USB 3.0
– 2x HD audio
– 1x power switch
– Maximum CPU cooler height: 160 mm
– – Maximum graphics card length: 330 mm
– Maximum net part length: 220 mm
