CM Stacker 830 has proven to be the leader among all chassis with its streamlined aluminum design and extremely powerfull functionality. Now, CM Stacker 831, the newer and improved Stacker series not only is equipped with the highly praised features from its predecessor, but also incorporates the suppor t for the new Raptor X technology. In addition, enhanced air ow design and extra suppor t for 230mm EPS powersupply make Stacker 831 a must-have every PC Enthusiasts want to lay their hands on.
This ground-breaking chassis is designed with value-added functionality, unmatched upgradability, tool-free user friendliness, and the superior thermal management.
CM Stacker 830 has proven to be the leader among all chassis with its streamlined aluminum design and extremely powerfull functionality. Now, CM Stacker 831, the newer and improved Stacker series not only is equipped with the highly praised features from its predecessor, but also incorporates the suppor t for the new Raptor X technology. In addition, enhanced air ow design and extra suppor t for 2...
CM Stacker 830 has proven to be the leader among all chassis with its streamlined aluminum design and extremely powerfull functionality. Now, CM Stacker 831, the newer and improved Stacker series not only is equipped with the highly praised features from its predecessor, but also incorporates the suppor t for the new Raptor X technology. In addition, enhanced air ow design and extra suppor t for 2...
No products found
Features
Value-added functionality
-Front panel opens to the left or to the right for easy access
-Power supply may be installed up wards or downwards for better airflow and neat cable manager.
Unmatchable upgrade ability
-Supports up to nine 5.25 drives
-Multi-Positioning for the 4-in-3 device modules, providing maximum flexibility in the use of space
Tool-free user-friendliness
-Screwless slots
-Side-opening design for remove 5.25 shield easily
Superior Airflow
-Accommodates up to nine 120mm fans
-High ventilation openings on the top and the sides for excellent thermal Management
Elegant&Robust Design
-THe balance brought out by elegant silver and sleek black colors enrich the appearance
-Solid construction and streamlined aluminum design
Specifications
Available Color Silver / Black ( Black Mesh)
Dimension (W / H / D) 250mm x 536mm x 638mm
M/B Type E-ATX, ATX, m-ATX,
Material Aluminum : 1.0 mm
Weight Net Weight : 14 kg
3.5 Drive Bay 4 (Hidden) from one 4-in-3 Device Module included;,
Two 3.5 face plates included
5.25 Drive Bay 9 (Exposed)
I/O Panel Dual I/O Panel in front and top USB 2.0×4(Support HD Audio)
Cooling System Front: 120mm x 1
Rear: 120 x 1
Support up to 9 x 120 mm fans (optional),
-Front fan x 3 (optional)
-Top fan x 1 (optional)
-Rear fan x 1 (optional)
-Side fan x 4 (side tray and bracket is optional),
-Bottom Air Inlet (optional)
Expansion Slots 7
Power Supply Standard ATX PS2 (optional),
