WCUK Spec 240M - Watercooled PHANTEKS Enthoo Evolv M-ATX - Gun Metal

About our Cases

These premium cases are professionally assembled here by the WCUK tech team, we pride ourselves on providing the customer with excellent perfoming hardware that we choose to be the best in range and what we would recomended on a daily basis to customers.

All our pre-installed cases are built to order and ship with the coolant filled and ready for you to install you latest hardware. (we can ship them dry on request so you can fill the system yourself once everything is installed).

Only the best quality hose and compression fittings are used in our setups as standard to ensure that a leak free journey from here to you and all the way up until you feel the need to upgrade or move on to better things is gauranteed. All Cases ship with a full 12 Month RTB warranty.

All our cases are leak tested for 24 hours prior to shipment, when the case arrives with you the only thing you need to do is unbox all your new hardware and let the installation begin, we recomend that you run a further leak test before you switch the power on to your Motherboard.

All cases come with a 24pin PSU bridging tool which enables you to run your PSU without having to power your Motherboard during your own leak test.

Case Spec

PH-ES314E_AG – Phanteks stands for innovation, quality and uniqueness – a reputation that the young company has achieved in a short time. With its cool and strong, specially coated processor coolers and excellent fans, both in terms of smoothness and flow rate. And in terms of design you sat with new shapes and colors much joy accents. With the luxury Big-Tower Primo, the Dutch not only presented the first representatives of their Enthoo series, but also their first computer case at all.

The Phanteks Enthoo Primo could convince away with its distinctive elegant design, the massive features and its overwhelming support for internal water cooling from the spot, but still remained a prohibitive hardware treasure for many.

Technical details:
     Dimensions: 230 x 450 x 400 mm (W x H x D)
     Weight: 9 kg
     Material: Steel (Body), aluminum (outer side)
     Color: Anthracite
     Form Factor: Micro-ATX, Mini-ITX
     Fan total possible:
     1x 200 / 2x 140/120 mm (front)
     1x 140/120 mm (rear)
     2x 140/120 mm (cover)
     Of this pre-installed:
     1x 200 mm (front)
     1x 140 mm (rear)
     Radiator Mountings (partial waiver of HDD and / or fan-Slots)
     1x max. 240/140 mm (front)
     1x max. 120/140 mm (rear)
     1x max. 240/280 mm (lid, up to 68 mm height)
     Filters: front, power supply (removable), cover
     Drive Bays:
     1x 5.25 inches (external, backward; removable)
     3x 3.5 inch (internal, 2x tools)
     6x 2.5 inch (internal; 4x instead of 3x 3.5 inches;
     1x SSD bracket behind the motherboard tray with Drop-n-Lock + 1x optionally
     Power supply: 1x Standard ATX (optional, max 216 mm in length.)
     Expansion Slots: 4
     I / O Panel:
     2x USB 3.0 (internal links)
     1x per Audio In / Out
     Maximum video card length: 318 mm
     Maximum CPU cooler height: 192 mm
     Maximum power supply Length: 180 mm (without any waiver)
     Maximum power supply Length: 216 mm (without HDD cage)

Watercooling Spec

Please note: These parts are installed as standard unless you select any custom options from above. Custom options replace standard installed parts and is an upgrade price from standard not as well as.

Installed Watercooling (as standard)
– 1x EK Water Blocks EK-Supremacy EVO (Select Socket Above)
– 1x Coolgate Double HD240 (High Density FPI) Radiator (Installed in top panel)
– 2x Phanteks PH F120SP 1300 RPM 120mm White LED fan
– 1x 12V DCP450 Super Quiet Pump/Reservoir 450lph
– 2x 3/8 ID – 5/8 OD Clearflex 60 Hose 1m (OR Select Type Above)
– Generic, Nickel Plated Silver Compression Fittings (OR Select Type Above)
– Alphacool Ultra Pure Water + Anti Algae treatment (OR Select Type Above)

Things to Note

We do try our best to keep stock of all items at all times, however if there is any picking issues with this case or if anything is not available we may exchange this for a like for like (performance) alternative. Should this happen, we will contact you.

Cases are all built to order and depending how busy we are and if everything is in stock the build time can be a few days. We will keep you up to date with the build progress by way of email.

On arrival, if you need assistance please do not hesitate to contact us using the support system.

We ship CPU Waterblock installation instructions and a 24Pin ATX Bridging tool with every case.
