- SKU: CPAK-090
- MPN: AK-CC4039HP01
- EAN: 4710679553849
Sapphire is one of if not the most popular manufacturer of AMD Radeon graphics cards. Also responsible for the success of Sapphire graphics cards is the award-winning cooling technology, which is now automatically transferred to the area of the CPU cooler. The Sapphire Vapor-X CPU cooler uses the Vapor Chamber cooling design and is designed for a cooling capacity up to 200 watts.
Sapphire Vapor-X CPU Cooler - 120mm
Sapphire is one of if not the most popular manufacturer of AMD Radeon graphics cards. Also responsible for the success of Sapphire graphics cards is the award-winning cooling technology, which is now automatically transferred to the area of the CPU cooler. The Sapphire Vapor-X CPU cooler uses the Vapor Chamber cooling design and is designed for a cooling capacity up to 200 watts.
Sapphire is one of if not the most popular manufacturer of AMD Radeon graphics cards. Also responsible for the success of Sapphire graphics cards is the award-winning cooling technology, which is now automatically transferred to the area of the CPU cooler. The Sapphire Vapor-X CPU cooler uses the Vapor Chamber cooling design and is designed for a cooling capacity up to 200 watts.
Featured products
No products found
Vapor-Chamber of Vapor-X is Similar to the graphics card in direct contact with the surface of the CPU, the heat dissipation improved. The heat is removed by a group of heat pipes and cooling fins. Then the heat of two fans with special blades that provide efficient airflow, but generate little operating noise, transported outside.
The two 120 mm fans are similar to those of the much-vaunted SAPPHIRE Dual X-series graphics cards and feature 4-pin PWM connectors. The included mounting kit allows use with most LGA sockets.
Technical details:
Dimensions (with fan): 135 x 163.5 x 110.4 mm (W x H x D)
Weight (with fan): ca. 924 g
Material: Copper (heatpipes), aluminum (slats)
Heatpipes: 4x Ø 7 mm, Vapor Chamber
Fan: 2x 120 mm (max 40 dB (A), approximately 495-2200 U / min, a max, 130.8 m³ / h.
Connectors: 4-pin PWM
Compatibility:
Intel Socket 775, 1151, 1155, 1156, 1366, 2011 2011 v3
AMD Socket AM2, AM2 +, AM3, AM3 +, FM1, FM2
