When NZXT KRAKEN X61, which comes in 280-mm-format dual radiator, the cooling capacity and the resulting volume are no longer only controlled by the fan speed of the included 140mm fans, but additionally also on the Motorgeschwindkeit the pump between 2,400 and 3,600 rev / min can be. The pump is as usual back integrated into the CPU water-block, which rests with its copper surface on the AMD or Intel processor.
On the back of Waterblocks also another unique feature of NZXT complete water cooling systems is to be found in the X61: The built here HUE lighting is a true highlight of the KRAKEN. With the RGB LEDs of the HUE system, it is possible to illuminate the NZXT logo and the surrounding lines depending on performance and convenience in a variety of colors, what preying on the mainboard lot.
The connection to the motherboard via USB while the fans are controlled as usual type FX-140 V2 via 4-pin PWM connector from the motherboard. It is to revised versions of the FX fans, the new 140-mm fans were even better on static pressure optimized (max. 1.97 mmH2O!) So that the unilateral placement of the fan 27 mm thin radiator of the sandwich Equipping with bilateral fans in nothing.
NZXT provides the user with the new CAM software to adjust even the possibility of the hand pump and fan performance itself. So if you want to adjust the balance between cooling and volume or between pump and fan speed yet, instead of relying on the out-of-the-box settings, at the KRAKEN X61 has the chance. In addition, here also current hydro and nuclear temperature are specified and it can switch between two different profiles even.
Whats the point? Because you can then use and control two OCTOPUS-cooling in a single system. An X61, X41 or X31 on the processor, the other example with the optional add-in adapter G10 GPU on a graphics card. NZXT Thus equipped the AiO area with the KRAKEN X61 a strong shot of innovations that are joined to the well-known advantages of a complete water cooling:
They are very cool strong work relatively low noise, are highly compatible (here: every modern socket from AMD and Intel), require no maintenance and fit in some small cases inside that can accommodate sweeping tower air cooler no place. The KRAKEN X61 comes prefilled and with voraufgetragener thermal paste on the CPU contact surface. Thanks to 40 cm long hoses, the radiator can be flexibly at two adjacent 140-mm fan slots positioned in the housing.
The high-quality compact water cooling KRAKEN X61 is considered by NZXT with a warranty of around six years, what is read, how sustainable the principle of the AiO-Water Coolings works.
Technical Details:
radiator:
Dimensions: 312.5 x 140 x 27 mm (W x H x D)
Material: Aluminum
pump:
Engine speed: 2400-3600 (+/- 150) U / min
Voltage: 12 V
Current: 325 mA
Connection: USB
LED lighting: freely selectable
fan:
Type: 2x 140 mm (FX140 V2)
Speed: 800 to 2000 U / min (+/- 10%)
Stroke: 71.6 to 179.3 m³ / h
Static Pressure: 0.36 to 1.97 mm H2O
Volume: 20 – 37 dB (A)
Connector: 4-pin PWM
Hose length: about 40 cm
compatibility:
Intel socket 1150, 1155, 1156, 1366, 2011, 2011-3
AMD Sockets: AM2, AM2 +, AM3, AM3 +, FM1, FM2, FM2 +
Manufacturer Warranty: 6 years
features:
With monitoring and control option via CAM software
Full HUE color control for the lighting of Water Blocks
Complete water cooling system with easy installation
Pre-charged and maintenance free, applied thermal paste pre-
High cooling capacity at the same time quiet operation
High quality 140 mm fan from NZXT included
high Compatibility
