PHANTEKS Eclipse P360A midi tower, tempered glass, D-RGB - black

The full mesh front allows for a generous supply of air and keeps dust out of the inside of the case. Behind it are two powerful PWM fans, which provide atmospheric light with their digitally addressable RGB-LED lighting. Of course, a side panel made of tempered glass must not be missing so that the built-in gaming hardware really comes into its own.

The features of the PHANTEKS Eclipse P360A at a glance:
– Noble midi tower with side panel made of tempered glass
– For mainboards up to an E-ATX form factor
– Stylish mesh front with two RGB LED fans
– Plenty of space for air or water cooling
– Graphics cards up to 400 mm in length, CPU coolers up to 160 mm in height
– 2x 2.5-inch slots & 2x 3.5-inch slots
– I / O panel with 2x USB 3.0 and 2x RGB control

The PHANTEKS Eclipse P360A: stylish design with optimized airflow
The trapezoidal front consists entirely of a close-meshed ventilation grille made of steel. The perforations, which are only one millimeter in size, ensure that the sucked in air gets dust-free and yet unhindered into the interior of the housing. Behind it, two 120 mm fans with PWM control and digitally addressable RGB-LED lighting are already installed ex works. They can be replaced by two 140 mm fans. The front is easy to remove and clean.

There is space for a 120 mm fan on the back. Either two 120 mm or two 140 mm fans can be attached to the cover. Accordingly, radiators can be accommodated in the Eclipse P360A, the radiator can be 240 mm on the lid and up to 280 mm on the front. There is still space for a 120 mm heat exchanger at the rear. The housing is equipped with a pull-out dust filter on the underside and a magnetic filter on the lid.

Plenty of space for gaming hardware
E-ATX mainboards with a maximum width of 280 mm have space in the interior of the Eclipse P360A. The processor installed on it can be cooled with a CPU cooler up to 160 mm high. There is also plenty of space for graphics cards, they can be up to 400 mm long. And for power supplies in the standard ATX format there is also plenty of space with 250 mm under the power supply cover, which not only hides cable clutter, but also the two HDD bays. On the back of the mainboard tray there is a lot of space for cable management with 36 mm.

Two 3.5-inch hard drives are housed in the HDD cage under the power supply cover. There are a total of three slots on the back of the mainboard tray for 2.5-inch drives, brackets are included for two of them. Another 2.5-inch SSD bracket is available from PHANTEKS as an optional accessory as well as a replacement for the seven PCI slots that can be replaced by a bracket with 3 PCI slots for vertical GPU installation.

On the top left is the I / O panel with the two buttons for controlling the RGB controller, one controls the RGB effects of the two RGB LED fans on the front, the other controls the colors. There are also two USB 3.0 slots, the almost ubiquitous audio jacks and of course – in the middle – the power switch.

Technical details:
– Dimensions (W x H x D): 200 x 455 x 465 mm
– Weight: 6.7 kg
– Material: steel, tempered glass, plastic
– Color: Black
– Form factor: E-ATX (up to 280 mm wide), ATX, Micro-ATX, Mini-ITX
– Total fans possible:
– – 2x 120/140 mm (front)
– 2x 120/140 mm (cover)
– 1x 120 mm (rear)
– Pre-installed:
– 2x 120 mm (front)
Radiator mountings:
– 1x max. 280 mm (front, max. 122/142 x 315 mm)
– 1x max. 240 mm (top, with max. 38 mm component height on the mainboard)
– Filter: front, power supply, cover (removable)
Drive bays:
– 2x 2.5 inches (behind mainboard tray)
– 2x 3.5 inches (internal)
– Power supply: 1x standard ATX (optional)
– Expansion slots: 7
I / O panel:
– 1x power button
– 2x LED controller
 -2x USB 3.0
– 2x 3.5 mm jack (1x mic-in / 1x audio-out)
– Maximum graphics card length: 400 mm
– Maximum CPU cooler height: 160 mm
– Maximum power supply length: 250 mm
