With the H440 in the ENVYUS Special Edition Premium manufacturer NZXT closes the gap between the smaller H230 and the larger H630 - where the former provides enough space for many dignified (and possibly water cooled) system and the latter too bulky fails, the H440 steps into the breach and proves to be the perfect compromise between versatility, feature richness and compactness. All the usual low NZXT price and the durable quality, which have proved the creators often enough.
With the H440 in the ENVYUS Special Edition Premium manufacturer NZXT closes the gap between the smaller H230 and the larger H630 - where the former provides enough space for many dignified (and possibly water cooled) system and the latter too bulky fails, the H440 steps into the breach and proves to be the perfect compromise between versatility, feature richness and compactness. All the usual low...
With the H440 in the ENVYUS Special Edition Premium manufacturer NZXT closes the gap between the smaller H230 and the larger H630 - where the former provides enough space for many dignified (and possibly water cooled) system and the latter too bulky fails, the H440 steps into the breach and proves to be the perfect compromise between versatility, feature richness and compactness. All the usual low...
No products found
The H440 outs himself already at first glance as a proud representative of the Silent Housing Family H from NZXT. In design especially inspired by the great big tower-brother, it has also to the series typical insulation the right side part and the front part, which here vibration transmissions and the leakage of sound waves are reduced. But the Silent concept only goes on because NZXT also considered a closed configuration of the land, especially in the front end.
The seen in many cases before the three mesh here placed and from work already fully populated fan slots would destroy the idea of a particularly silent computer case. But the designers succeeded then, breathe the fans to leave? Simply by having integrated a nearly continuous white-black grille strips in the outer edges of the matt black, metal-tipped plastic front. Thus, air can be sucked without causing much sound leaking to the outside.
In Top one trusts the same principle, with optional fan would be provided here by default throw. As the front are also three 120 or two 140-mm-slots available, which can accommodate radiators instead of fans, namely the way up to 280-dual or even 360s triple heat exchangers (z. B. from NZXT OCTOPUS X60 ). For a case of the compact class a staggeringly good watercooling preparation! If you want to leave it with fans, will also appreciate the large 140-mm model that NZXT has installed in the rear.
In addition, a fan manifold is integrated into the H440, can be connected to up to ten 3-pin fan – that is, one can more propellers with electricity via the fan hub, than ever can be installed into the case, so that the fans are taken into consideration by processor coolers or alternative graphics card heatsinks. Speaking of graphics card: Also, the H440 comes with the practical switchable LED lighting at the seven PCI slots, which facilitate the exchange of expansion cards immensely.
Three things makes NZXT in H440 but in a different way than its predecessors. Thus, there are no external 5.25-inch bays for optical drives more because more and more PC users can now dispense entirely with the use of optical media such as DVDs. In turn, appears the front panel design is closed and the whole room in the front third of the midi tower stands for internal drives. Again, attempts NZXT times out something new.
In H440, there are no HDD cages in the strict sense, in which Cage per multiple drives are inserted, but several separate slots for each of a 3.5-inch hard drive (or optional 2.5 inch). What is the advantage here? You can remove each rack individually, to make way for example to a certain level an overlong graphics card (to 40.6 cm!), And you do not have to do without it with a match on several hard drives or SSDs.
The third innovation concerns the rectangular side windows in the left panel, a first in the series of NZXT Silent housing. The great thing is that NZXT has created a case that can be kept incredibly clean inside. So the window the front drive area saves one hand completely, so that the data and power cables to the storage media does not even appear. Secondly, the verbauende to power supply is down behind a hidden Shroud, which shines on the window side with a blue decorative plate together with illumination NZXT lettering.
The PSU is characterized not only invisible, but also thermally largely decoupled from the rest of the interior. Thus, CPU, VGA, RAM heat on one side and power supply on the other side not to unnecessarily on each other. All cables from the Shroud continued behind the motherboard tray, for which 15.6 to 26.4 mm are available. Thanks to numerous partially rubberized openings all components be achieved ideal and the visible cable routes remain maximally short. The two USB 3.0 and 2.0 ports complete the lush features the NZXT H440.
Technical details:
Dimensions: 220 x 513 x 480 mm (W x H x D)
Material: Steel (Body), plastic (front cover)
Weight: approx 9.8 kg
Matte Black, Blue, White (ENVYUS Special Edition)
Form Factor: ATX, Micro-ATX, Mini-ITX
Fan Hub: 10x 3-pin fan
Fan total possible:
2x 140 / 3x 120 mm (front)
1x 140/120 mm (rear)
140 2x / 3x 120 mm (lid)
Of preinstalled:
3x 120 mm (front FN V2)
1x 140mm (rear FN V2)
Radiator Mountings (partial waiver of drive and / or fan slots):
1x max. 280/360 mm (front)
1x max. 140 mm (rear)
1x max. 280/360 mm (lid)
Filter: Front, Power Supply
Drive Bays:
6x 3.5 inch (internal; tools)
7x 2.5 inch (internal; 5x instead of 3.5 inches)
PSU 1x standard ATX (optional)
Expansion Slots: 7
I / O panel:
2x USB 3.0 (internal connection)
2x USB 2.0 (internal connection)
2x per Audio In / Out
Maximum video card length: 294 mm (with HDD cages)
Maximum video card length: 428 mm (without HDD cages)
Maximum CPU cooler height: 180 mm
