The considerable increase in performance of the GK110 GPU, the here offered by Gainward GeForce GTX 780 Ti partly the result of more shader units , namely now 2,880 . For comparison, the GTX Titan comes to 2688 and the GTX 780 without the Ti ( Tanium ) shortcuts to 2,304 CUDA cores . On the other hand NVIDIA increases the standard clock rates and Gainward rotates additionally to the timing screw so that the factory overclocked Gainward GTX 780 Ti Phantom works with 980 MHz base clock and per GPU Boost 2.0 – depending on the available reserves of energy consumption and heat generation – on can accelerate around 1046 MHz.
But not only the core clock it has in the Gainward GTX 780 Ti Phantom in itself , also of 3072 MB ( 3 GB) GDDR5 video memory clocked at 3,500 (ie 7,000 effective ! ) MHz unlikely high. Along with the 384 -bit wide access of the video RAM on the Kepler GPU is itself the liquid Game calculation of so-called hardware -eater at 4K resolutions and multi- monitor setups no longer a problem – antialiasing included!
To temperatures and volume but not to lose at so high gaming power out of sight, Gainward GTX 780 Ti Phantom of missed a proprietary cooling layout that can not only convince by its black appearance . For use in addition to five 8-mm heatpipes are also equal to three fans who do not sit on the heat sink , but below it . This is the 2.5 slots GTX 780 Phantom high stay cooler not only under load than in the reference design , but the cooler is to make less noise at idle . The fans are the perfect maintenance even taken out individually ! Power is supplied via two 8- pin PCIe connectors.
NVIDIA GeForce GTX 780 excited at the Ti also by other measures such as Adaptive Vertical Sync , the exclusive Kantenglättungsmodi FXAA and TXAA , support for PCI Express 3.0 , the dedicated video engine NVENC , the ability to SLI and 3D Vision (Surround) or in the driver integrated software tool GEFORCE EXPERIENCE . This is possible without a long trial and error , by comparing it with a massive database , perfect settings for each computer in each game !
In order to exploit the full potential of the card in the future , new drivers from NVIDIA or Gainward should be downloaded and installed at regular intervals.
Technical details :
Dimensions: 274 x 112 mm (W x D)
Height: 2.5 – Slot
GPU: NVIDIA GeForce GTX 780 Ti
Type: Kepler GK110
Manufacturing process: 28 nm
GPU clock : 980 MHz
Boost Clock: 1046 MHz
Shader units ( CUDA cores ) , 2880
Memory Size: 3072 MB
Memory clock: 3,500 ( 7,000 ) MHz
Type: GDDR5
Memory bus : 384 bit
Slot : PCIe x16 ( PCI / PCIe 2.x/PCIe 3.0)
connections:
1x DisplayPort 1.2
1x HDMI 1.4
1x DVI -I ( dual link)
1x DVI -D ( dual link)
Power supply: 2x 8-pin PCIe
Recommended power supply – output: min. 600 watts ( 42 amps on the 12 volt rail )
Features: DirectX 11, DirectCompute 5.0, OpenGL 4.4, OpenCL , 3D Vision Surround, tessellation , PhysX , CUDA , NVENC , SMX , GPU Boost 2.0 , Adaptive Vertical Sync , SLI, G-Sync
Compatibility (operating system ): Windows 8, 7 , Vista , XP
