The Midi-Tower iVektor has been developed for heavy gaming PCs and workstations. Sporty lines and distinctive air intakes dominate the exterior of the housing. The new soft-grip surface coating enhances the body visually, protects from scratches and absorbs vibrations and noise.
Up to six fans see the iVektor place, two of which can be controlled by the speed controller on the top. A 12-cm rear fan is standard equipment. The top panel has a recess for 240mm radiators or two 12-cm fan.
The Midi-Tower iVektor has been developed for heavy gaming PCs and workstations. Sporty lines and distinctive air intakes dominate the exterior of the housing. The new soft-grip surface coating enhances the body visually, protects from scratches and absorbs vibrations and noise.Up to six fans see the iVektor place, two of which can be controlled by the speed controller on the top. A 12-cm rea...
The Midi-Tower iVektor has been developed for heavy gaming PCs and workstations. Sporty lines and distinctive air intakes dominate the exterior of the housing. The new soft-grip surface coating enhances the body visually, protects from scratches and absorbs vibrations and noise.Up to six fans see the iVektor place, two of which can be controlled by the speed controller on the top. A 12-cm rea...
No products found
The installation of drives and hard disks are tool and without screws. The side walls of the upper HDD cage can be put, so that both 2.5 drives (HDD / SDD) and 3.5 hard drives can be installed. Optical drives are simply inserted and automatically lock (patented SlideIn ™ system). For longer video cards, or to improve air circulation inside the case, users can also remove the upper HDD cage completely. On the top there are two USB 3.0 ports, two USB 2.0 ports and HD audio ports.
design
iVektor – Soft Grip. Hard Drive.
Strong and functional mid-tower with a high performance double cooling system and user-friendly design for gaming machines and workstations.
Soft grip coating
Great rubberized surface with a pleasant feel. The soft-grip coating dampens vibration, reduces noise and protects the body from fingerprints and scratches.
compatibility
Multi-GPU Support
Seven slots allow the installation of up to three graphics cards.
Flexible HDD / SSD cage
Practical, multifunctional HDD cage with displaceable side wall. When fastening the side wall in the outer position of the cage can accommodate up to four 3.5 HDDs / SSDs. By displacing the holder in the middle position up to four 2.5 drives (HDD / SSD) can be mounted. In addition, the side wall can be removed completely to improve air circulation and oversized graphics cards up to 415 mm in length.
cooling
Powerful cooling system
A 12-cm rear fan included. Generous expandability up to 6 fans: Slots for two 12cm front fan, two 12-inch ceiling fan and a 12-cm fan on the floor.
Three-stage fan control
Integrated speed control via a switch on the top of the housing. Controlling the preinstalled rear fan in three stages. Connection for another fan.
Ideal for water-cooled systems
Supports water cooling systems with 120mm radiators and – depending on the mainboard model – 240 mm below the top of radiators. Two rubber hose leads on the case back.
Disk Management
Sophisticated data storage
Room for up to seven (HDD & SSD): A hard drive cage for three 3.5 HDDs / SSDs as well as a flexible HDD cage for four 3.5 HDDs / SSDs or four 2.5 -HDD / SSDs.
Protection against shock
HDD rails with rubber pads for effective vibration damping.
Data transfer with maximum speed
Two USB 3.0 ports on the top for ultra fast data transfer speeds up to 5 Gbits / s.
Installation, cable management and operation
Patented Slide-In ™ system for optical drives
The new screwless Slide-In ™ system from Enermax is the fastest and easiest way to install optical drives. When inserting the drives are automatically locked.
Generous cable management
Holes and brackets for accurate and hidden cable routing. With its generous 30 mm space behind the motherboard tray and punched side panel.
Optimum protection against dust
Integrated dust filter in the front, on top of the housing and base.
Bottom-side power supply assembly
Better cable routing and optimized cooling by installing the power supply at the bottom of the housing. Easy to clean dust filter underneath the power supply. Rubber pads for decoupling and vibration damping.
Tool-free HDD installation
Quick and easy mounting of disks (HDDs / SSDs) with the included drive rails without screws, and additional tools.
Technical data:
Model ECA3311A-B
Type ATX Mid-Tower
Color: Black
Black interior painting
Material SECC / soft-grip coating
Dimensions (W x H x D) 234mm x 508mm x 495mm
Drive Bays 5.25 3x
Drive Bays 3.5 7x (4x removable)
Drive Bays 2.5 4x (by converting the upper HDD cage)
Supported motherboard formats ATX, mATX
Interfaces on top 2x USB 3.0, 2x USB 2.0, HD Audio, fan control
Cooling – front optional: 2x 12cm fan
Cooling – top optional: 2x 12cm fan or 1x 240mm radiator *
Cooling – Floor optional: 1 x 12-cm fan
Cooling – Rear panel preinstalled: 1x 12cm fan
Max. Length of installation for graphics cards 290mm / 322mm / 415mm (depending on the upper HDD cage)
Max. Mounting height for CPU Cooler 179mm
Slots for expansion cards 7x
Ducts for water cooling 2x
